Posted on

Ultrapitch (simplified) Mod for Numark PT01



This is a Simplified Ultrapitch Modification for the Numark PT01

Parts needed:
Resistor between 1k ohm and 2k ohm

notes:
-when the platter speed switch is set the 33rpm, the platter will spin at ~22rpm
-when the platter speed is set to 45rpm, the platter will spin at 33rpm
-this mod can only be done on newer (example 2014) PT01 turntables
-older models, such as circa 2006, have a different motor control circuit and require a different mod
-the new models have the orange potentiometer shown below, where the older models have a blue potentiometer
-download the “RPM – the turntable speed accuracy checker” iPhone app to test platter speed
-this mod came from a forum comment by Rasteri, which said “Replace VR1 with a 2K resistor and that lowers the 33RPM speed to about 20RPM”
-buy Dj Focus’ ultrapitch mod for full control, and to support the skratch community
-works with ultrapitch 7” records, such as skiratcha breaks from DJ A1

-Remove and Replace VR1
1. Unsolder the potentiometer in VR1

2a. Solder a resistor across the 2 pins shown in pic_1_replace_VR1. This picture shows a 2.2k ohm resistor in place of VR1. This results in a platter speed of ~20rpm, when the platter speed switch is set to 33rpm, and ~32rpm when set to 45rpm (varies between turntables).

pic_1_replace_VR
pic_1_replace_VR

-Alternate VR1 values
2b. It was found through test that a 960 ohm resistance across VR1 results in a clean 33rpm, when the platter speed switch was set to 45rpm. This resistance results in 22rpm, when the platter speed switch is at 33rpm. A 820 ohm and 150 ohm resistor were connected in series to achieve ~970 ohms. The resulting speed vs. resistance value depends a lot on the friction between the spindle and the platter. A value between 1k and 2k ohm should work great. see pic_2_replace_VR1_series

pic_2_replace_VR1_series
pic_2_replace_VR1_series

Posted on

3D Printed Tonearm Clip Install for Numark PT01

Featured Video Play Icon



Adds 3D Printed Tonearm Clip to the Numark PT01

Parts needed:
3D printed tonearm clip

notes:
-only for use with 3D printed tonearms

-Install 3D Printed Tonearm Clip
1. Remove white backing paper from tonearm clip
2. Stick 3D printed tonearm clip onto existing PT01 tonearm clip. Make sure the orientation of the 3D printed clip base matches the existing PT01 tonearm clip, before sticking (one side is round, one side is square)

Posted on

Faceplate Removal for Numark PT01

Featured Video Play Icon



How to Remove the Numark PT01’s Metal Faceplate

Parts needed:
plastic pick, such as a guitar pick
plastic putty knife (any plastic putty knife from your local hardware store will work. Preferably, not more than a couple inches wide)

notes:
-always use plastic tools for the procedure to avoid faceplate and plastic housing does not get scratched
-the metal faceplate is applied to the plastic turntable housing with heavy double sided tape
-the adhesive sticks to the faceplate better than the housing, so there is little damage to the housing, when removed
-the plastic housing below the faceplate is black
-there is no need to paint or replace the faceplate, if a black faceplate is desired
-removing the faceplate exposes a spring and a hole for the spring, which is a good place to add a switch or knob
-the spring is attached to the housing with a single screw (no solder). Remove the screw to remove the spring.

-Remove the tonearm
1. See tonearm removal guide

-Start at the 45 Adapter
2. Starting at the 45 adapter hole, use a plastic pick and gently pry up the faceplate. The 45 adapter hole is a good place to start, because it doesn’t have a beveled edge to protect the faceplate.
3. Lift the corner of the faceplate from the 45 adapter hole enough to fit a second plastic pick or putty knife along the outer edge of the faceplate (see pic_1_45_adapter)

pic_1_45_adapter
pic_1_45_adapter

-Pry Outer Edge
4. Work around the outer edge of the faceplate. Be careful not to pry too far up, or the faceplate will bend (see pic_2_outer_edge)

pic_2_outer_edge
pic_2_outer_edge

-Pry Inner Faceplate
5. Use a plastic putty knife to pry the deeper sections of the faceplate, such as between the platter and the EQ controls (see pic_3_putty_knife)

pic_3_putty_knife
pic_3_putty_knife

-Lift Faceplate Off
5. Use your hands to lift/pry the faceplate the rest of the way off. Be careful not to cut your hands on the edge of the metal faceplate.

-Mount a Start/Stop switch in the Spring Hole (optional)
6. See start/stop switch guide

Posted on

Start/Stop Switch Install for Numark PT01

Featured Video Play Icon



Adds start/stop switch to the Numark PT01

Parts needed:
SPST (Push 0n – Push off) Switch

notes:
-any push on – push off or latching switch with a greater than ~300mA rating will work for this
-the switch listed above was used for this install
-if you remove the PT01 faceplate, this switch fits in the existing spring hole without drilling (remove the spring, which is attached internally with one screw)

-Remove the Existing Switch
1. Unsolder and remove the existing start/stop switch (see pic_1_remove_switch)

pic_1_remove_switch
pic_1_remove_switch

-Mount the New Switch
2. Mount the new switch in a preferred location (see pic_2_mounted switch). For this guide, the switch is mounted in the existing spring hole with the faceplate removed (see faceplate removal guide for instructions on removing the faceplate).

pic_2_mounted switch

-Solder Wires
3. Solder 2 wires to the existing switch PCB (see pic_3_add_wires)

pic_3_add_wires
pic_3_add_wires

4. Solder these wires to the new switch (see pic_4_connect_switch)

pic_4_connect_switch

Posted on

Platter Bar Install and Comparison

Featured Video Play Icon



How to Install Platter Bars for the Numark PT01

Parts needed:
platter bars
needle nose pliers

Optional Parts:
silicone grease

notes:
-there are at least 2 different platter heights for the PT01
-the older model, circa 2006, has a low platter height
-the newer model, circa 2014, has a high platter height
-one clear difference between models is that the belt holder attached to the motor is plastic on the 2006 model, and metal on the 2014 model

-Remove Platter
1. Use a pair of pliers to push off the spindle clip (see pic_1_remove_spindle_clip)

pic_1_remove_spindle_clip
pic_1_remove_spindle_clip

2. Push on one edge of the platter to raise the opposite edge

3. Lift the platter using the raised edge, and remove platter (see pic_2_remove platter)

pic_1_remove_spindle_clip
pic_1_remove_spindle_clip

-Install Platter bar
4. Remove white adhesive backing from platter bar (see pic_3_platter_bar_backing)

pic_3_platter_bar_backing
pic_3_platter_bar_backing

5. Place the wide edge of the platter bar flush against the turntable wall (see pic_4_place_platter_bar)

pic_4_place_platter_bar
pic_4_place_platter_bar

6. Cut or break off the 2 nubs on the bottom side of the platter (they have no functionality). This will stop the nubs from potentially hitting the platter bars. See pic_6_cut_nub

pic_6_cut_nub
pic_6_cut_nub

7. Reinstall the platter and platter clip.
a. wrap the turntable belt around the inner edge of the platter first
b. place the platter on the spindle, while pulling on the belt with one finger to keep tension
c. wrap the belt, which is being held with one finger, around the motor spindle
d. reinstall platter clip using pliers

8. Turn on the motor and let the platter spin. If the platter rubs on the the platter bars, push down hard on the platter and move it back and forth in a baby scratch motion. This will grind down the platter bar’s plastic housing. Turn on the motor again to see if the platter still rubs on the platter bars. Repeat until the platter stops rubbing on the platter bar during playback. See “How to Grind Down Platter Bars Video”, below:

How to Grind Down Platter Bars Video:

Platter Bar Comparison Video:

Posted on

Stock Needle vs. shure M44-7 + Pyle PP444 (objective comparison)

This comparison includes a needle and tonearm comparison table, spectrums, and a tap test video.

Turntable 1:
-stock Numark PT01 USB

Turntable 2:
-modified Numark PT01 USB
3D printed tonearm
-shure M44-7 cartridge and needle
Pyle PP444 stereo phono preamp (requires preamp mod)

notes:
-data was taken to objectively compare the stock ceramic needle and tonearm to a 3D printed tonearm with M44-7 needle and Pyle PP444 preamp on a Numark PT01
-data includes output level testing using a “Cardas Frequency Sweep and Burn-In Record” as source material
-audio data is taken with an Audio Precision APx515 audio analyzer
-The Pyle PP444 phono preamp was chosen for it’s very low cost, and +9V (single rail) operation
-a much higher quality preamp can be used if desired
-top level view, the data says that the output level is similar between turntable 1 and turntable 2
-the m44-7 has a bit more low end
-the ceramic needle has a bit more high end
-the m44-7 is louder with a 1kHz tone audio source
-the ceramic needle is louder with a pink noise audio source
-the ceramic needle has a lower noise floor when the platter is moving
-the m44-7 has a lower noise floor when the patter is not moving
-the m44-7 has less record wear
-the m44-7 has better anti-skate performance when bouncing (i.e. more likely to land back on the correct skipless scratch section of the record)
platter bars will help with bounce performance for both needles

-Needle and Tonearm Comparison Data
1. See the Needle and Tonearm Comparison Table, and associated spectrums

Needle and Tonearm Comparison Table

Test Description Ceramic Needle (mVrms) M44-7 with Pyle PP444 Preamp (mVrms)
Channel 1 Channel 2 Channel 1 Channel 2
1kHz tone, full volume, flat EQ 245 219 307 276
1kHz tone, full volume, Hi EQ 284 251 364 327
1kHz tone, full volume, Low EQ 198 176 276 242
Tonarm docked, no input (noise floor test) 0.752 0.735 0.407 0.397
Tonearm undocked, no input (noise floor test, platter moving) 1.63 1.69 7.78 7.1
Pink Noise, full volume, flat EQ 505 451 322 327
Pink Noise, full volume, Hi EQ 673 585 351 363
Pink Noise, full volume, Low EQ 293 214 285 280



table notes:
-all data taken with Audio Precision APx515
-both turntables were wall powered for all tests
-the 1kHz and pink noise audio source was generated by playing source material from the “Cardas Frequency Sweep and Burn-In Record” vinyl record
-“Cermaic Needle” refers to the Numark PT01 stock needle
-“M44-7” refers to a shure M44-7 cartridge mounted on a 3D printed tonearm
-“with Pyle PP44” refers to a modified Numark PT01, where the existing preamp is bypassed, and a Pyle PP444 is installed in it’s place
-“flat EQ” refers the tone control knob in center position
-“Hi EQ” refers to the tone control knob in “High” position
-“Low EQ” refers to the tone control knob in the “Low” position

-Spectrums
2. See spectrums

Ceramic Needle, 1kHz Tone, Full Volume
Ceramic Needle, 1kHz Tone, Full Volume

M44-7 plus Pyle PP444, 1kHz Tone, Full Volume
M44-7 plus Pyle PP444, 1kHz Tone, Full Volume
Ceramic Needle, Pink Noise, Full Volume
Ceramic Needle, Pink Noise, Full Volume
M44-7 plus Pyle PP444, Pink Noise, Full Volume
M44-7 plus Pyle PP444, Pink Noise, Full Volume

-Bounce Performance
3. See the tap test video

Posted on

3D Printed Tonearm Counterweight Adjustment

Featured Video Play Icon



How to Adjust the Counterweight for a 3D Printed Tonearm

Parts needed:
3D printed tonearm

notes:
-the scale used for test is a 5g (maximum) stylus scale, with 0.01g precision
-the sure m44-7 needle expects 3-5g of weight for optimal tracking and audio performance

-Check Weight of Needle
1. Check the weight of the needle using a stylus scale (first measured weight is at 3.48g, see video)

-Adjust Counterweight
2a. Increase the counterweight by removing tension from the counterweight rubber band. In this case, the rubber band moves from the inside position to the outside position to reduce tension (second weight is at 4.26g, see video).

2b. Tension can also be adjusted by using a rubber band of a different thickness, and also by stretching or releasing tension in the section of the rubber band between the base of the tonearm and the back of the tonearm

Posted on

Rechargeable Battery Install

Featured Video Play Icon



Adds 12V rechargeable Lithium Ion battery to the Numark PT01

Parts needed:
12V rechargeable battery
DC plug (2.1mm x 5.1mm)
Picture hanging Strips (optional, or can be substituted):

notes:
-Disconnect the rechargeable battery from the PT01, when powering the PT01 from a wall supply.
-Charge the battery by disconnecting the DC plug from the battery, and charge it using it’s supplied charging wall supply.
-The battery power switch must be on, while charging the battery (explained in the battery instructions, but are in Chinese)
-Turn the battery power switch off, when not in use to save charge (not required).
-see LM7805 data sheet for more info on the PT01 regulator (actual part number is LM7809)

-Connect Wires to the PT01 Power Supply Input
1. On the PT01 power supply PCB, solder a GND wire (black) to the center pin (pin 2) of the LM7809 regulator (see pic_1_PT01_regulator)

pic1_PT01_regulator
pic1_PT01_regulator

-Connect DC Plug
3. Confirm whether the center pin of the DC plug needs to be + or – by reading the label on your rechargeable battery. The center pin is + for the battery listed above.
4. If using the battery listed above, solder the red wire to the center pin of the DC plug (see pic_2_DC_plug)

pic2_DC_plug
pic2_DC_plug

5. If using the battery listed above, solder the black wire to the outer ring of the DC plug (see pic_2_DC_plug)

-Mount Battery
6. The battery can be mounted however you like. I like the using the picture hanging strips listed above. One strip is mounted on the wall of the PT01 within the battery compartment (sticky side against wall), and one strip gets mounted on the battery (sticky side against battery). I put a set of strips on 2 sides of the battery (example: side and top). This is rock solid, and allows the battery to be removed, if necessary (see pic3_Battery_placement).

pic3_Battery_placement
pic3_Battery_placement
Posted on

Preamp Modification

Featured Video Play Icon



Adds a Pyle PP444 Preamp to the Numark PT01

Parts needed:
Pyle Pro PP444
-Hook-up wire for connections

notes:
-the 12V rechargeable battery mod is highly recommended for use with this preamp mod
-the rechargeable battery mod, which gets regulated by the PT01, will remove power supply noise injected into the preamp by unregulated 9V D cell batteries
-the rechargeable battery mod is not required if you only use the wall power supply (it is regulated by the PT01).

-Disassemble PP444
1. unbox pp444
2. remove 4 housing screws from the PP444 and remove cover
3. remove 2 PCB screws
4. remove 2 panel mount screws (screws by RCA connectors)
5. remove PCB from enclosure

-Connect Tonearm Wires to PP444 Input
6. On the PT01 PCB, unsolder tonearm wires from J8, J9, and J16 (L_in, GND, and R_in)
7. Solder these wires to the bottom side of the PP444 PCB. see pic_1_tonarm_wires_to_pp444

pic_1_tonearm_wires_to_pp444
pic_1_tonearm_wires_to_pp444

-Connect PP444 Output to Numark PT01 Input
8. On the PT01 PCB, remove the 4 mounting screws.
9. On the PT01 PCB, unsolder and remove capacitors C8 and C18. see pic_2_c8_c18, and pic3_c8_c18_removed

pic_2_C8_C18
pic_2_C8_C18
pic_3_C8_C18_removed
pic_3_C8_C18_removed

10. On the PT01 PCB, solder 3 new wires to the 3 locations shown in pic_4_PT01_input

pic_4_PT01_input
pic_4_PT01_input

11. On the bottom side of the PP444 PCB, solder these 3 wires to the location shown in pic_5_PP444_output

pic_5_PP444_output
pic_5_PP444_output

-Connect the 9V Power Supply of the PT01 to the PP444
12. On the bottom side of the PP444 PCB, solder 2 new wires to the location shown in pic_6_PP444_9V_power

pic_6_PP444_9V_power
pic_6_PP444_9V_power

13. On the bottom side of the PT01 PCB, connect these 2 wires to pins 2 and 3 of TE11. see pic_7_PT01_9V_output

pic_7_PT01_9V_output
pic_7_PT01_9V_output

-Quick Test Before Final Install
14. Reassemble the turntable (no need for screws) and test for functionality. Use the wall power supply to power the PT01.

-Final install
15. Hot glue all of the new solder points. This acts as a strain relief for the wires.
16. Reinstall the PT01 PCB with 4 screws
17. Wrap the PP444 PCB with electrical tape or polyimide (kapton) tape (see pic_8_PP444_tape). This is to avoid any potential shorts between the PP444 PCB, and the PT01

pic_8_PP444_tape
pic_8_PP444_tape

18. Set the PP444 PCB on top of the PT01 PCB (see pic_9_PP444_location),with the RCA connectors of the PP444 PCB facing the battery compartment.

pic_9_PP444_location
pic_9_PP444_location

19. Reassemble the turntable.

Extra credit:
-On the PP444 PCB, remove all of the large connectors (RCA, etc.). This is not required, but will make it much smaller. This will make step 19 easier.

Posted on

3D Printed Tonearm Install

Featured Video Play Icon



Adds an m44-7 Compliant Tonearm to the Numark PT01

Parts needed:
3D printed tonearm
needle nose pliers

notes:
-connecting the shure m44-7 to a stock PT01 reduces audio output loudness (due to cartridge/preamp mismatch)
-the preamp mod is highly recommended for use with the m44-7, which boosts the m44-7 loudness
-this tonearm mod improves skating, when bouncing
-add platter bars for best bounce performance

-Remove Existing Tonearm
1. See tonearm removal guide

-Bend Small Wires
2. Bend the small wires to a 90 degree angle form the wire housing to make an “L” shape (see pic_1_L_shape_wire)

pic_1_L_shape_wire
pic_1_L_shape_wire

-Install wire
2. Starting at the back side of the tonearm, and place the thick insulated part of the wire in the trough of the tonearm.
3. Slide the thick part of the wire along the trough towards the headshell. Allow the small wires to pass through the tight restraint sections of the tonearm. Don’t pull on the small wires. Just push the thick part of the wire, and guide the small wires through the restraint (see pic_2_wire install)

pic_2_wire_install
pic_2_wire_install

4. Continue sliding the wire through the tonearm until the small wires reach the headshell (see pic_3_wire_install_2)

pic_3_wire_install_2
pic_3_wire_install_2

-Mount the Cartridge
5. Connect the m44-7 or preferred cartridge to the tonearm wires
6. Mount the m44-7 to the headshell, by placing the nut on the topside of the headshell, and the screw/washer on the cartridge side (see pic_4_mount_m447)

pic_4_mount_m447
pic_4_mount_m447

-Install the Tonearm (David) Axle Rod
7. Place the tonearm on the tonearm base
8. Push the side of the rod that does not have a star on it through the tonearm (see pic_5_install_rod)

pic_5_install_rod
pic_5_install_rod

9. Guide the rod through the tonearm, metal tonearm base of the turntable, and opposite side of the tonearm
10. Press fit the star side of the rod into the tonearm plastic using a needle nose pliers (pic_6_press_fit_rod)

pic_6_press_fit_rod
pic_6_press_fit_rod

-Install Rubber Band Counterweight
11. Wrap the rubber band around the headshell side of the tonearm, and slide it towards the tonearm base (see pic_7_add_rubber_band)

pic_7_add_rubber_band
pic_7_add_rubber_band

12. Wrap the rubber band around the metal tonearm base (not the plastic part of the tonearm), and pull towards the back (see pic_8_rubber_band_base)

pic_8_rubber_band_base
pic_8_rubber_band_base

13. Align the rubber band with the grooves on the back of the tonearm, and attach to a tonearm peg (see pic_9_rubber_band_peg)

pic_9_rubber_band_peg
pic_9_rubber_band_peg

14. Adjust rubber band tension to control counterweight (see 3D printed tonearm counterweight adjustment guide)
